DB9

52.36m

2010

Top Speed32kts
Cruise Speed24kts
Range4000nm
Displacement287t
Beam9.5m
Guests10
Guest Cabin5
Crew11

Build & Design

Specifications

Overview

  • Name:DB9
  • Yacht Type:Motor Yacht
  • Yacht Subtype:Semi-displacement, Sports/Open Motor Yacht

Dimensions

  • Length Overall:52.36m (171' 9")
  • Beam:9.5m (31' 2")
  • Max Draught:2.44m (8' 0")
  • Gross Tonnage:495.00
  • Displacement Tonnage:287.00

Construction

  • Builder:Palmer Johnson
  • Year of Build:2010
  • Hull Number:PJ 501 (170/1)
  • Hull Type:Semi Displacement
  • Number of Decks:2

    Performance & Capacities

    • Max Speed:32.50kn
    • Cruising Speed:24.40kn
    • Range (nm):4000.00nm @ 13.00kn
    • Consumption:1400.00L / 369.84USG
    • Fuel Capacity:59308.00L / 15667.52USG
    • Water Capacity:6900.00L / 1822.79USG

    Engines

    • Make:MTU
    • Model:16V2000M93
    • Type:Diesel
    • Quantity:2
    • Total Power:9226.00hp

    Materials

    • Hull:Aluminium
    • Superstructure:Aluminium
    • Deck:Teak

    Accommodation

    • Guests:10
    • Passenger Rooms:5
    • Master Rooms:1
    • Double Rooms:2
    • Twin Rooms:2

    Classification

    • Classification:LR
    • MCA Compliant:Yes
